TERASON USMART 3200T ULTRASOUND Features:

SuperHarmonicTM Imaging Power
256 GB Solid State Drive (SSD)
Smart Gestures
uConnect® remote capabilities
Enhanced Needle Visualization (ENV)
Smart CaseTM for added protection and durability
Up to a Five Year Warranty

A fusion of cutting-edge technology and ease of use, the uSmart 3200T brings you crystal-clear images, grab-and-go portability, and an intuitive user interface that defines simplicity. With exclusive Enhanced Needle Visualization (ENV), the uSmart 3200T is one powerful machine.

Take advantage of Terason’s true open architecture to streamline
workflow and easily store data.

Open architecture for file management
256 GB SSD
Easy integration with EMR
Easily transfer DICOM images to PACS
Bluetooth compatibility
Wireless networking available
DICOM Structured Reporting (DICOM SR)

TERASON USMART 3200T ULTRASOUND System Specifications :

Imaging Modes
• 2D (B-Mode)
• M-Mode
• Color Doppler
• Pulsed Wave Doppler
• Power Doppler
• Directional Power Doppler
• Continuous Wave Doppler
• Tissue Doppler
• Tissue Harmonic Imaging
with
SuperHarmonics
Imaging Features
• Enhanced Needle Visualization (ENV)
• TeraVision™ II
• OmniBeam™
• Dynamic Depth Resolution (DDR™)
• TeraZoom™
• Trapezoid
• Triplex/Duplex
(Simultaneous/Non-Simultaneous)
• Split Screen
• Full Screen
• Auto Optimization
• 2D Beam Steering
• Application-Specific Presets
• Post Processing
• TeraScape™
• Intima-Media Thickness (IMT)
System Features
• Touch Screen with Smart Gestures™
• 11.6″ Backlit High-Resolution LCD
with Gorilla® Glass
• 480 GB Solid State Drive (SSD)
• Still Frame Image Export (BMP, JPEG)

• uSmartScan™ Exam Protocol
Software, Programmable Exam
Protocol Software
• Dynamic Clip Export (AVI)
• DICOM 3.0 Compliant
• DICOM Structured Reporting
(DICOM SR)
– Cardiac
– Vascular
• uConnect® Remote Capability
• USB 3.0 Port
• Ethernet Port
• SD Memory Card Slot
• Wireless and Bluetooth
• Stereo Speakers
• Headphone Jack
• Cold Boot-Up Time: < 45 Seconds
• Smart Mark™
• Smart Guide™
• Micro HDMI Port
• Removable Battery and DC Input
• Built-in 5 Megapixel Camera
Measurement Packages
• Cardiology
• OB
• Vascular
Operating System
• Windows® 10
Physical System Specifications
System Dimensions:
• Height: 9″ / 230 mm
• Width: 13″ / 327 mm
• Depth: 1.25″ / 36 mm
• System Weight: 4.85 lb / 2.23 kg

Mobile Cart
• Multi-Probe Connector Kit (Optional)
• 3 Transducer Holders
• 1 Active Probe Holder
• Thin, Sleek Body Style
• Mobile Design
• 4-Wheel Steering for
Excellent Mobility
• 4 Locking Wheels
• Shelf with Handle and
Removable Gel Holder
• On-Cart Storage Basket
• Transducer Connector Holders
with Cable Management Hooks
Mobile Cart Physical Specifications:
• Weight: 37 lb / 16.78 kg
• Work Surface Height: 38″ / 96.52 cm
• Height: 52″ / 132.08 cm
• Base Diameter: 20″ x 20″ /
50.80 cm x 50.80 cm
